We are updating various boards in the BRi-LPS series.

• LPS Board Ver. 2.2 (LPS01 Series)
• LPS Board Ver. 3.1 (LPS02 Series)

The BRi-LPS01 Series will be updated to Ver. 1.2, and the price will increase by 2,000 JPY.
There will be no price change for the BRi-LPS02 Series.

Changes from LPS Board Ver. 2.0 (BRi-LPS01 Ver. 1.1) to Ver. 2.2 (BRi-LPS01 Ver. 1.2)

• Based on feedback regarding the LPS board Ver. 3.1,
  the through-hole metal film resistors have been replaced with Vishay MMB MELF 1% metal film resistors.

• The through-hole diodes in the protection circuit have been replaced with SMD (surface-mount) components; by mounting them on the reverse side, noise countermeasures have been implemented by shortening the circuit traces for the protection circuits around the regulator, relay and output terminals.

• The reverse current protection circuit has been changed to Kyocera SMD Schottky barrier diodes, as in the LPS board Ver. 3.1

• By adding a VH connector (along with short-circuit and reverse current protection circuits) to the board as a second output terminal for optional use, the board now supports an additional output terminal (panel-mounted terminal) as an option

Changes from LPS Board Ver. 3.0 (BRi-LPS02) to Ver. 3.1 (BRi-LPS02 Ver. 1.1)

• Replace the through-hole metal film resistors in the relay and voltage determination circuits with Vishay MMB MELF 1% metal film resistors

We will update the content on each page as and when necessary, although this may take some time.
For further details, please contact us via the contact form.
